Blister Packing Machine With Liquid Feeder And Peristaltic Pump

Furis Group Co Ltd
Contact Now
    Buy cheap Blister Packing Machine With Liquid Feeder And Peristaltic Pump from wholesalers

    Buy cheap Blister Packing Machine With Liquid Feeder And Peristaltic Pump from wholesalers
    • Buy cheap Blister Packing Machine With Liquid Feeder And Peristaltic Pump from wholesalers
    • Buy cheap Blister Packing Machine With Liquid Feeder And Peristaltic Pump from wholesalers
    • Buy cheap Blister Packing Machine With Liquid Feeder And Peristaltic Pump from wholesalers

    Blister Packing Machine With Liquid Feeder And Peristaltic Pump

    Ask Lasest Price
    Brand Name : FRS
    Model Number : DPB-250
    Certification : CE
    Price : 15000-30000USD/SET
    Payment Terms : D/A, D/P, L/C, T/T, Western Union
    Supply Ability : 1-5 sets one month
    • Product Details
    • Company Profile

    Blister Packing Machine With Liquid Feeder And Peristaltic Pump

    PLC Liquid Filling Blister Packing Machine With Peristaltic Pump


    Applying:


    Our DPB-250 Liquid pill tablet blister packing machine is a latest high-precision medicine packing machine in current pharmacy industry. It is widely used for capsule, tablet, honey pills in pharmaceutical industry, for milk tablet, candy, chocolate in food industry, for injector, syringes, pins, small component etc. In electron or hardware industry as all kind of shapes of ALU-ALU,ALU-plastic, paper-plastic combined sealing packing.


    Feature:


    1.The key electric appliance of his machine adapts PLC processor, temperature modular, touch screen to operate, high quality product, can be equipped with cursor device etc. as customer`s requirement. 2.Machine-tool track type of casting machine-base, taken these processing like backfire, maturing, high benchmark and without distortion.

    3.Each box of section processed through professional equipment, to assure high precision and good exchangeability.

    4.Forming, sealing, slitting etc. parts are all could be adjust freely on the track with triangle string and flat string, strong applicability. small oversize, save installation space.

    5.Reducer adapts parallel-axes bevel wheel, to avoid loose and smooth between chain or strap when it is driving.

    6.Stroke can be adjust freely, widely used, ease of operation, stable running.

    7.It adapts up and down net pattern concavo-convex to conjugate, multi-step air cylinder, double-heat sealing. Quality sealing


    Parameters:


    ModelDPB-250
    Cutting Frequency(times/min)6-35(I) 20-60(II)
    Capacity (strip/h)8400(I) 12000(II)
    Max Shaping Areas and Depth(mm)240*160*26
    Stroke(mm)20-120(can be manufactured as user`s requirements)
    Standard Sheet(mm)80*57(can be manufactured as user`s requirements)
    Air Pressure(kw)0.4-0.6
    Total Power380V/220V 50Hz 6kw
    Pressure(kw)1.5
    PVC Hard Pieces(mm)0.15-0.5*250
    PTP Aluminum Foil(mm)0.02-0.035*250
    Dialysis Paper(mm)50-100g*250
    Mould Coolingtap water or back water
    Overall Dimensions(mm)2710*720*1600
    Weight(kg)1600

    W


    We can offer you different capacity different function blister packing machine




    Competitive Advantage:


    1. We have several technicians who gets passport ready to travel all over world to offer service to you.
    2. We have 24hours hot line for Technical Support.
    3. We get 18hours internet line for technical support.
    4. Video camera in workshop to help you adjust and solve machine problem in working situation.
    5. We have Technical Support in below Country:
    USA (Distributor ),Italy distributor,Britishi(Distributor),India(Distributor)


    Comany info:


    We are mainly produce the pharma machine,pharma packing machine,Our product includes labeling machine,capsule filling machine,tablet press machine,powder mixing machine,powder grinding machine,tablet capsule counting machine,blister packing machine,cartoning machine,
